2.5-6k-MTL-S
Single phase on grid growatt solar power inverter 1kw 2kw 3kw 4kw 5kw solar inverter
1,Growatt 1000-S | 1500-S|2000-S | 3000-S
Leading - edge Technology
Maximum efficiency of 97.6% and wide input voltage / range
Internal DC switch / Transformerless GT topology
Compact design / Ethernet / RF technology / WiFi
Sound control / Easy installation
Comprehensive Growatt warranty program
2,Growatt 2500MTL-S | 3000MTL-S| 3600MTL-S | 4200MTL-S| 5000MTL-S | 5500MTL-S
Leading - edge Technology
Double MPPT Tracker, MPPT tracking accuracy more than 99.5%
Max. Efficiency 97.6%, European Efficiency 97%(Growatt 2500MTL-S | 3000MTL-S)
Max. Efficiency 97.9%, European Efficiency 97.4%(3600MTL-S | 4200MTL-S 5000MTL-S | 5500MTL-S)
Integrated DC switch for added safety protection Transformerless design and high power density, offer lighter and more convenient installation Power factor continuously adjustable Flexible communication connection, support RF, WiFi, Ethernet Comply with European, Asia-Pacific safety regulations
3,Growatt 2000HF | 3000HF | 5000HF
Leading - edge Technology
Maximum efficiency of 96.5% and wide input voltage range DC switch optional High frequency Compact design MTL - String Ethernet / RF technology / Wi-Fi Sound control Fanless cooling concept Easy installation High reliability
| Datasheet | Growatt 1000-S | 1500-S 2000-S | 3000-S |
Growatt 2500MTL-S | 3000MTL-S | 3600MTL-S | 4200MTL-S 5000MTL-S | 5500MTL-S |
Growatt 2000HF | 3000HF | 5000HF |
| Input data (DC) | ||||
| Max. recommended PV power (for module STC) |
1300-3400W | 2900-3500W | 4100-5750W | 2300-5500W |
| Max. DC voltage | 450-550V | 500V | 550V | 600V |
| Start voltage | 80V | 100V | 100V | 150V |
| PV voltage range | 70V-550V | 70V-500V | 70V-550V | 100V - 600V |
| MPP work voltage range/ nominal voltage |
70-550V/180-360V | 80V-500V /360V | 80V-550V /360V | 120V - 600V/(380V/410V) |
| Full load dc voltage range | 110-500V | 130V-450V | 150V-500V | 195V - 480V |
| Max. input current | 10-13A | 10A | 10-15A | 12-24A |
| Max. input current per string | 10-13A | 10A | 10-15A | 12-24A |
| Number of independent MPP trackers /strings per MPP tracker |
1/1 | 2/1 | 2/1 | 1 / 2,2 / 1 |
| Output (AC) | ||||
| Rated AC output power | 1000-3000W | 2500-3000W | 3600-5000W | 2000-5000W |
| Max. AC power | 1000-3000W | 2500-3000W | 3600-5000W | 2000-5000W |
| Max. output current | 4.7-14.3A | 11.3-13.6A | 16.3-22.7A | 10-23A |
| AC nominal voltage; range | 220,230,240V; 180Vac-280Vac |
220V/230V /240V; 180Vac-280Vac | 220V/230V/240V; 180Vac - 280Vac |
220V230V240V; 180Vac-280Vac |
| AC grid frequency; range | 50,60 Hz;±5 Hz | 50Hz,60Hz /±5Hz | 50Hz,60Hz / 5Hz | 50,60Hz;±5Hz |
| Power factor | 1 | 1 | 1 | >0.99 |
| THDI | <3% | |||
| AC connection | Single phase | |||
| Efficiency | ||||
| Max. efficiency | 97.4-97.6% | 97.6% | 97.9% | 96.3-96.5% |
| Euro-eta | 96.5-97.3% | 97% | 97.4% | 95.5% |
| MPPT efficiency | 99.5% | 99.5% | 99.5% | 99.5% |
| General Data | ||||
| Dimensions (W / H / D) in mm | 271*267/320*142 | 355*419*138 | 355*419*138/158 | 386/362/154 mm,362/474/195 mm |
| Weight | 6.1-8.8kg | 14kg | 14-14.5kg | 13.6-20KG |
| Operating temperature range | –25°C ... +60°C | |||
| Noise emission (typical) | ≤25 dB(A) | |||
| Self-Consumption night | <0.5 W | |||
| Topology | Transformerless | |||
| Cooling concept | Natural | |||
| Environmental Protection Rating | IP65 | |||
| Altitude | 2000m without derating | |||
| Relative humidity | 100% | |||
